PAYLOADS / OP SERIES
OP-80T 4K 80x EO/IR Spherical Gimbal Camera, 256x192 Thermal
OP-80T is a 4K tri-sensor EO/IR spherical UAV payload for missions that need visible-light zoom, thermal awareness and target measurement in one pod. It combines 80x zoom imaging, 256x192 native thermal imaging with 512x384 super resolution, intelligent measurement, AI-HDR, AI-ISP and AI multi-object detection and tracking.
Price guide
US$???9
DETAILS
Product Details
- Tri-sensor EO/IR payload combines 4K zoom imaging, thermal sensing and target measurement.
- 512x384 thermal super resolution improves thermal observation beyond the native 256x192 sensor output.
- AI-HDR and AI-ISP improve image clarity in high-contrast and low-light scenes.
- AI multi-object detection and tracking supports people and vehicle monitoring.
Applications
- Thermal inspection and search missions
- Public safety and emergency response
- Industrial inspection and security monitoring
- Night operation and low-visibility observation
SPECIFICATIONS
Specifications
| General | |
|---|---|
| Product Name | OP-80T |
| Dimensions | 89.6 x 86 x 124.6mm |
| Weight | 430g |
| Operating Voltage | 20 ~ 53 VDC |
| Power | 7.0W (Static, laser ranging off) / 25.5W (Stall, laser ranging on) |
| Gimbal | |
| Gimbal Type | 3-axis Nonorthogonal Mechanical Stabilization |
| Angular Accuracy | ±0.01° |
| Controllable Range | Pitch: -145°~+60°, Yaw: ±360° constantly |
| Max Controllable Speed | 150°/s |
| Wide-angle Camera | |
| Image Sensor | 1/2.8-inch CMOS; Effective Pixels: 8.29M |
| Lens | Focal Length: 6.1~61.4mm (Equivalent focal length: 41.6~415.8mm) |
| Resolution | 3840(H) x 2160(V) |
| Pixel Pitch | 1.45um(H) x 1.45um(V) |
| Optical Zoom | 10x |
| Equivalent Digital Zoom | 8x |
| Thermal Camera | |
| Thermal Sensor | Uncooled VOx Microbolometer |
| Lens | Actual Focal Length: 7mm (Equivalent focal length: 78.9mm) |
| Resolution | Native: 256(H) x 192(V) / Super resolution: 512(H) x 384(V) |
| Pixel Size | 12um(H) x 12um(V) |
| Equivalent Digital Zoom | 8x |
| Spectral Band | 8~14um |
| Laser Range Finder | |
| Wavelength | 905nm |
| Max Laser Power | 1mW |
| Laser Safety | Class 1 (IEC 60825-1:2014) |
| Measurement Accuracy | <=50m: ±0.25m / 50m~100m: ±0.5m / 100m~300m: ±1m / >300m: ±2m |
| Measurement Range | 3-1200m daylight / 3-2000m night, @12m vertical surface with 20% reflectivity |
| AI Multi-object Detection & Tracking | |
| Object Size | 16x16 ~ 128x128 px |
| Object Identification Delay | <40ms |
| Tracking Speed | ±32 px / field |
| Tracking Deviation Refresh Rate | 30Hz |
| Tracking Deviation Output Delay | <=5ms |
| Image & Video | |
| Maximum Image Resolution | 3840 x 2160 |
| Maximum Video Resolution | Stream: 3840 x 2160; Recording: 3840 x 2160 |
| Stream Network Protocol | RTSP |
| Storage | |
| Supported SD Cards | Supports a U3/V30 or above MicroSD card with a capacity of up to 256GB |
| Environment | |
| Operating Temperature | -20C ~ 50C |
| Storage Temperature | -40C ~ 60C |
| Operating Humidity | <=85%RH (Non-condensing) |
KEY TAKEAWAYS
- Weighs 430g at 89.6 x 86 x 124.6mm, which sets the airframe and mount it fits.
- 3-axis Nonorthogonal Mechanical Stabilization holds ±0.01° angular accuracy.
- Runs on 20 ~ 53 VDC drawing 7.0W (Static, laser ranging off) / 25.5W (Stall, laser ranging on) — budget this against your platform's spare payload power.
- 3840(H) x 2160(V) through a Focal Length: 6.1~61.4mm (Equivalent focal length: 41.6~415.8mm) lens.
OP Series models compared
| Model | Weight | Dimensions | Stabilization | Angular accuracy | Resolution | Input voltage |
|---|---|---|---|---|---|---|
| OP-125A | 1055g | 142 x 125 x 187mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 2688(H) x 1520(V) | 20 ~ 53 VDC |
| OP-80A | Pod: 429g; GCU: 18.6g | Pod: 85.8 x 86 x 129.3mm; GCU: 45.4 x 40 x 13.5mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 1920 x 1080 | 14 ~ 53 VDC |
| OP-80N | 398g | 89.6 x 86 x 124.6mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 1920(H) x 1080(V) | 20 ~ 53 VDC |
| OP-80P | Pod: 405g; GCU: 18.6g | Pod: 85.8 x 86 x 129.3mm; GCU: 45.4 x 40 x 13.5mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 3840 x 2160 | 14 ~ 53 VDC |
| OP-80R | 398g | 89.6 x 86 x 124.6mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 3840(H) x 2160(V) | 20 ~ 53 VDC |
| OP-80T | 430g | 89.6 x 86 x 124.6mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 3840(H) x 2160(V) | 20 ~ 53 VDC |
| OP-80U | 398g | 89.6 x 86 x 124.6mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 3840(H) x 2160(V) | 20 ~ 53 VDC |
| OP-90A | Pod: 608g; GCU: 18.6g | Pod: 96.4 x 96 x 147mm; GCU: 45.4 x 40 x 13.5mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 1920 x 1080 | 14 ~ 53 VDC |
| OP-90D | Pod: 576g; GCU: 18.6g | Pod: 96.4 x 96 x 147mm; GCU: 45.4 x 40 x 13.5mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 1920 x 1080 | 14 ~ 53 VDC |
| OP-90N | 620g | 96.4 x 96 x 147mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 1920(H) x 1080(V) | 20 ~ 53 VDC |
| OP-90P | 620g | 96.4 x 96 x 147mm | 3-axis Nonorthogonal Mechanical Stabilization | ±0.01° | 3840(H) x 2160(V) | 20 ~ 53 VDC |
Frequently asked questions
How much does the OP-80T weigh?
OP-80T weighs 430g. Its dimensions are 89.6 x 86 x 124.6mm, so check both mass and envelope against your mount.
What power does the OP-80T need?
OP-80T accepts 20 ~ 53 VDC. Power draw is 7.0W (Static, laser ranging off) / 25.5W (Stall, laser ranging on). Confirm your platform can supply this continuously, not just at peak.
How is the OP-80T stabilized?
OP-80T uses 3-axis Nonorthogonal Mechanical Stabilization. Published angular accuracy is ±0.01°.
What is the OP-80T controllable range?
Pitch: -145°~+60°, Yaw: ±360° constantly. This is the mechanical travel available to the operator or autopilot.
What resolution does the OP-80T capture?
3840(H) x 2160(V).
What temperature range does the OP-80T operate in?
-20C ~ 50C. Outside this band the published specifications no longer apply.
